VDI Shank Floating Reamer Holders
Features:
- The free moving ball bearing drive allows reamers to follow the existing drilled hole for high quality work.
- Could be used for synchronized tapping operations on lathes and CNC machining centers.
- Through the shank coolant capability
| SHANK | COLLET | D | H | R | TOOL HOLDER | COLLET | COLLET |
| SIZE | SERIES | PART NO. | WRENCH | NUT | |||
| VDI20 | ER25 | 57 | 57 | 1 | VDI20ERFC25 | ER25EW | ER25E |
| VDI30 | ER25 | 68 | 64 | 1 | VDI30ERFC25 | ER25EW | ER25E |
| VDI30 | ER32 | 68 | 72 | 1.5 | VDI30ERFC32 | ER32EW | ER32E |
| VDI40 | ER32 | 83 | 74 | 1.5 | VDI40ERFC32 | ER32EW | ER32E |
